High Speed Transmission UTP Cat6a Bulk Cable

Short Description:

Cat6a Ethernet cables mean the augmented Category 6 Ethernet cables. The Cat6a cable, the form of Gigabit Ethernet cabling, was defined in 2018. The Cat6a cable consists of tighter twisted pairs to avoid crosstalk interference. It has a transmission bandwidth ranging from 250 up to 500 MHz frequency. The Cat6a Ethernet cable is compatible with Cat6 and Cat5e cables.

Get A Quote Get Product Data

Product Detail

Product Tags

Product Parameter

Item	Value
Brand Name	EXC (Welcome OEM)
Type	UTP Cat6a
Place of Origin	Guangdong China
Numeber of Conductors	8
Color	Custom Color
Certification	CE/ROHS/ISO9001
Jacket	PVC/PE
Length	305m/rolls
Conductor	Cu/Bc/Cca/Ccam/Ccc/Ccs
Package	Box
Shield	UTP
Conductor Diameter	0.5-0.6mm
Operating Temperature	-20°C-75°C

Speed

The most distinctive difference between Cat6 and Cat6a is the data transmission speed. Both Cat6 cables and Cat6a cables can support data transmission rates to 10 Gbps. But Cat6 cables can only keep 10 Gbps to 37~55 meters (121~180 feet), and Cat6a cables can relay 10 Gbps up to 100 meters (328 feet).

Structure

In general, Cat6a cables can be thicker than Cat6 cables, so they also feature thicker cable jackets and copper conductors. Compared to Cat6 cables, Cat6a cables require higher standard RJ45 connectors and keystone jacks. In addition, Cat6a cables have tighter twisted pairs than Cat6 cables.

Bandwidth

Cat6a has a great upgrading as it has the double bandwidth frequency as Cat6. The bandwidth frequency of Cat6a cables can reach 500 MHz, which allows for more stable data transmission and longer distances.

Bend Radius

Usually, you should not bend a cable too much or it will damage the wiring and affect the performance. Bend radius means the minimum radius that a cable can be bent without damage. The bend radius mainly depends on the cable structure and materials. In general, bend radius is directly proportional to the diameter of cable. Because of the thickness and bulkiness, Cat6a cables have a larger bend radius than Cat6 cables and they can occupy more room.
